SKU: 6202ZZC3-NSK
NSK 6202ZZC3 Metal Shielded Deep Groove Ball Bearing 15x35x11mm
Equivalent to: 6202ZZEC3 62022ZC3 6202.2ZC3 62022ZRC3 6202FFC3
In stock
Price Break
Couldn't load pickup availability
Share this product
Description
Metal Shielded Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with metal shields inserted into the outer raceway, these fit in closely to the inner race providing protection against light mechanical damage, some protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing.
Shields can be removed for applications that don't require a shield or only require 1 shield.
Benefits: Provides light mechanical protection, limits moisture and dirt ingress, lubricated for life, cost-effective solution.
- Brand / Quality:
- NSK - High Quality
- Inside Diameter:
- 15mm
- Outside Diameter:
- 35mm
- Width:
- 11mm
- Seals / Shields:
- Metal Shielded
- Clearance:
- C3
Technical
| d | 15mm |
|---|---|
| D | 35mm |
| B | 11mm |
| r min | 0.6mm |
| Dynamic load Cr | 7650 N (780 kgf) |
| Static load Cor | 3750 N (380 kgf) |
| Factor | 13.2 |
| Speed in grease | 20000 rpm |
| Speed in oil | 24000 rpm |
| Weight | 0.045 kg |
