SKU: 6306/VA201-SKF

SKF 6306VA201 Single Row Deep Groove Ball Bearing High Temperature Type 30x72x19mm

Name: SKF 6306VA201 Single Row Deep Groove Ball Bearing High Temperature Type 30x72x19mm
Brand: SKF
SKU: 6306/VA201-SKF
Price: 68.00 USD
Availability: InStock

$68.00 ex VAT

Sale Sold out

In stock

Price Break

10+ $45.55

19+ $42.99

29+ $42.48

39+ $41.96

49+ $41.45

74+ $40.94

99+ $38.38

199+ $37.87

249+ $37.36

499+ $36.85

999+ $35.82

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF VA201 Series High Temperature Bearings: Supplied as an open type bearing are designed for high temperatures up to + 250 degrees Celsius and down to - 40 degrees Celsius. At temperatures over + 200 dry lubrication pertains. Designed for speeds up to 100rpm without maintenance. Internal clearance is C5 and all have a BLACK PHOSPHATED COATING
Benefits: High temperature resilience, low maintenance

Brand / Quality:: SKF - High Quality
Inside Diameter:: 30mm
Outside Diameter:: 72mm
Width:: 19mm
Seals / Shields:: None
Clearance:: * Standard

Technical

d	30mm
D	72mm
B	19mm
d1	44.6mm
D2	61.9mm
r1r2	1.1mm
Basic load rating Co	16 kN
Weight	0.35 kg
Max operating temp	+250 deg C
Min operating temp	-40 deg C
Recommended max speed	100 rpm
