• NTN 6814 Open Type Deep Groove Ball Bearing 70x90x10mm
  • NTN
1 2

SKU: 6814-NTN

NTN 6814 Open Type Deep Groove Ball Bearing 70x90x10mm

NTN 6814 Open Type Deep Groove Ball Bearing 70x90x10mm
$139.61 ex VAT
$139.61 ex VAT
Sale Sold out

Equivalent to: 6814CM 61814CM 61814T 61814 1814S 61814Y

In stock

Price Break
3+ $93.51
5+ $88.26
10+ $87.21
25+ $86.16
49+ $85.11
74+ $84.06
99+ $78.80
199+ $77.75
249+ $76.70
499+ $75.65
999+ $73.55

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
NTN - High Quality
Inside Diameter:
70mm
Outside Diameter:
90mm
Width:
10mm
Seals / Shields:
None
Clearance:
* Standard
Technical
--- Bearing dimensions
d 70mm
D 90mm
B 10mm
r<sub>s</sub> min 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 13.4 kN
C<sub>or</sub> 11.9 kN
C<sub>u</sub> 0.795 kN
f<sub>0</sub> 16.1 kN
Grease 6900 rpm
Oil 8100 rpm
--- Fitting Dimensions
d<sub>a</sub> Min. 74mm
D<sub>a</sub> Max. 86mm
r<sub>as</sub> Max. 0.6mm
Weight 0.137 kg
