SKU: 6814ZZ-NKE
NKE 6814ZZ Metal Shielded Thin Section Deep Groove Ball Bearing 70x90x10mm
NKE 6814ZZ Metal Shielded Thin Section Deep Groove Ball Bearing 70x90x10mm
Equivalent to: 6814ZZE 6814ZZ 6814.2Z 6814KDD 6814DD 6814FF68142ZR
Out of stock
Share this product
Description
Description
|
Metal Shielded Thin Section Ball Bearings: One of the most commonly used bearings, these types are manufactured with metal shields inserted into the outer raceway, these fit in closely to the inner race providing protection against light mechanical damage, some protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing. |
- Brand / Quality:
- NKE - High Quality
- Inside Diameter:
- 70mm
- Outside Diameter:
- 90mm
- Width:
- 10mm
- Seals / Shields:
- Metal Shielded
- Clearance:
- * Standard
Technical
Technical
| d | 70mm |
|---|---|
| D | 90mm |
| B | 10mm |
| Dynamic load C | 12.4 kN |
| Static load Co | 13.2 kN |
| Fatigue load limit Pu | 0.56 kN |
| Reference speed | 15000 rpm |
| Limiting speed | 4300 rpm |
| Weight | 0.14 kg |
| d1 | 76.6mm |
| d2 | 85.5mm |
| r1r2 min | 0.6mm |
| da min | 73.2mm |
| Da max | 86.8mm |
| ra max | 0.6mm |
| Calculation factor kr | 0.015 |
| Calculation factor f0 | 17 |
