• NSK 7007A5TRV1VSULP3 Super Precision Sealed Angular Contact Spindle Bearing 35x62x14mm
  • NSK
1 2

SKU: 7007A5TRV1VSULP3-NSK

NSK 7007A5TRV1VSULP3 Super Precision Sealed Angular Contact Spindle Bearing 35x62x14mm

NSK 7007A5TRV1VSULP3 Super Precision Sealed Angular Contact Spindle Bearing 35x62x14mm
$211.32 ex VAT
$211.32 ex VAT
Sale Sold out

In stock

Price Break
3+ $141.55
5+ $133.60
10+ $132.01
25+ $130.42
49+ $128.83
74+ $127.23
99+ $119.28
199+ $117.69
249+ $116.10
499+ $114.51
999+ $111.33

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
NSK - High Quality
Inside Diameter:
35mm
Outside Diameter:
62mm
Width:
14mm
Seals / Shields:
Rubber Sealed
Style:
Single Universal Matchable Bearing
Contact Angle:
25 Degree contact angle
Bearing Preload:
Light preload
Technical
--- Bearing dimensions
d 35mm
D 62mm
B 14mm
r<sub>min</sub> 1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 19.1Kn
C<sub>or</sub> 13kN
Axial load Kn 11.4 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 18.3mm
Max speed in grease 20700 rpm
Max speed in oil 31000 rpm
--- Fitting dimensions
d<sub>a min</sub> 41mm
D<sub>a max</sub> 56mm
D<sub>b max</sub> 57mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.5mm
Weight 0.151kg
