• NSK 7007CTRV1VDULP3 Super Precision Sealed Angular Contact Spindle Bearing 35x62x14mm (Set of 2)
  • NSK
1 2

SKU: 7007CTRV1VDULP3-NSK

NSK 7007CTRV1VDULP3 Super Precision Sealed Angular Contact Spindle Bearing 35x62x14mm (Set of 2)

NSK 7007CTRV1VDULP3 Super Precision Sealed Angular Contact Spindle Bearing 35x62x14mm (Set of 2)
$408.55 ex VAT
$408.55 ex VAT
Sale Sold out

In stock

Price Break
3+ $273.66
5+ $258.29
10+ $255.21
25+ $252.14
49+ $249.06
74+ $245.99
99+ $230.61
199+ $227.54
249+ $224.46
499+ $221.39
999+ $215.24

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
NSK - High Quality
Inside Diameter:
35mm
Outside Diameter:
62mm
Width:
14mm
Seals / Shields:
Rubber Sealed
Style:
Universal Matched Pair of Bearings
Contact Angle:
15 Degree contact angle
Bearing Preload:
Light preload
Technical
--- Bearing dimensions
d 35mm
D 62mm
B 14mm
r<sub>min</sub> 1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 20.1Kn
C<sub>or</sub> 13.7kN
Axial load Kn 9.35 kN
Contact angle 15 degrees
Factor f<sub>o</sub> 15
Effective diameter 13.5mm
Max speed in grease 23800 rpm
Max speed in oil 36100 rpm
--- Fitting dimensions
d<sub>a min</sub> 41mm
D<sub>a max</sub> 56mm
D<sub>b max</sub> 57mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.5mm
Weight 0.302kg
