75AT5/390/G3 ContiTech Gen III Synchroflex Timing Belt 75mm Width 5mm Pitch 78 Teeth

SKU: 75AT5/390/G3

75AT5/390/G3 ContiTech Gen III Synchroflex Timing Belt 75mm Width 5mm Pitch 78 Teeth

$142.32 ex VAT
$142.32
ex VAT
Not in stock

Quantity Price Breaks

3 $126.66
5 $119.55
10 $118.13
15 $116.70
20 $115.28
30 $113.86
40 $106.74
50 $105.32
60 $103.89
75 $102.47
100 $99.62
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
75AT5/390/G3 ContiTech Gen III Synchroflex Timing Belt 75mm Width 5mm Pitch 78 Teeth
SKU: 75AT5/390/G3

75AT5/390/G3 ContiTech Gen III Synchroflex Timing Belt 75mm Width 5mm Pitch 78 Teeth

$142.32 ex VAT
$142.32
ex VAT

Description

AT Generation 3 SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.

The Generation 3 (Gen III) Synchroflex belt construction consists of high-tensile steel cord tension members and wear-resistant polyurethane which makes this belt extremely durable and provides high performance. Also, this belt provides an impressive 25% increase in power transmission when compared to the AT/ATP standard.

Benefits: Low elastic elongation, high flank load capacity, 25% more power than standard AT and high-performance polyurethane & steel reinforced.

Technical

No of Teeth = 78
Belt Width = 75mm
Belt Pitch = 5mm (AT5)
Belt Length = 390mm
Belt Thickness (hs) = 1.5mm
Tooth Height (ht) = 1.2mm
Tooth Pitch (t) = 5mm
Flank Angle (f) = 50 deg
Tension Member Loadings = 6803 N
Belt Weight (per metre) = 0.27kg
