• NSK 7912A5TRV1VDBLP3 Super Precision Sealed Angular Contact Spindle Bearing 60x85x13mm (Set of 2)
  • NSK
1 2

SKU: 7912A5TRV1VDBLP3-NSK

NSK 7912A5TRV1VDBLP3 Super Precision Sealed Angular Contact Spindle Bearing 60x85x13mm (Set of 2)

NSK 7912A5TRV1VDBLP3 Super Precision Sealed Angular Contact Spindle Bearing 60x85x13mm (Set of 2)
$671.39 ex VAT
$671.39 ex VAT
Sale Sold out

In stock

Price Break
3+ $449.72
5+ $424.45
10+ $419.40
25+ $414.34
49+ $409.29
74+ $404.24
99+ $378.97
199+ $373.92
249+ $368.87
499+ $363.81
999+ $353.71

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
NSK - High Quality
Inside Diameter:
60mm
Outside Diameter:
85mm
Width:
13mm
Seals / Shields:
Rubber Sealed
Style:
Universal Matched Pair of Bearings
Contact Angle:
25 Degree contact angle
Bearing Preload:
Light preload
Technical
--- Bearing dimensions
d 60mm
D 85mm
B 13mm
r<sub>min</sub> 1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 19.2Kn
C<sub>or</sub> 17.7kN
Axial load Kn 13 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 23.4mm
Max speed in grease 13800 rpm
Max speed in oil 20700 rpm
--- Fitting dimensions
d<sub>a min</sub> 66mm
D<sub>a max</sub> 79mm
D<sub>b max</sub> 80mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.5mm
Weight 0.396kg
