• AXK6085 Major Branded Needle Roller Cage 60x85x3mm
1 1

SKU: AXK6085-MB

AXK6085 Major Branded Needle Roller Cage 60x85x3mm

AXK6085 Major Branded Needle Roller Cage 60x85x3mm
$15.29 ex VAT
$15.29 ex VAT
Sale Sold out

In stock

Price Break
10+ $10.25
19+ $9.67
29+ $9.55
39+ $9.44
49+ $9.32
74+ $9.21
99+ $8.63
199+ $8.52
249+ $8.40
499+ $8.29
999+ $8.06

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
AXK Series Needle Roller thrust Bearings: Needle roller and cage thrust assemblies are a low profile high load thrust bearing assembly and can be used with either the AS, LS or GS series thrust washers which are supplied separately, they are made up of a uniform cage which reliably guides a large quantity of needle rollers, the rollers are slightly relieved towards their outer edge to enable uniform load distribution and prevents any edge damage occurrence.
Benefits: Cost effective thrust solution, wide range, low profile, high load bearing
Brand / Quality:
Major Brand - High Quality
Inside Diameter:
60mm
Outside Diameter:
85mm
Width:
3mm
Technical
d 60mm
D 85mm
Dw 3mm
Ea 65mm
Eb 83mm
Dynamic load 37500 N
Static load 232000 N
Fatigue load limit Pu 28500 N
Speed in grease 1300 rpm
Speed in oil 1800 rpm
Weight (assembly) 33 g
d1 85mm
D 85mm
D1 62mm
B 4.75mm
