SKU: BB-6204EC44.5-B180-10-GL
xiros xirodur BB6204EC44.5B18010GL End Cap Ball Bearing 20x50x39mm - Allow 2-3 Days
xiros xirodur BB6204EC44.5B18010GL End Cap Ball Bearing 20x50x39mm - Allow 2-3 Days
Out of stock
Description
Description
|
IGUS xiros® xirodur® B180 Polymer End Cap Ball Bearings: These end cap bearings feature low-priced xirodur® B180, PA cages and glass balls. These bearings can be used as quiet-running, low-priced ball bearings. The independently developed material makes it possible to offer long service lifes and outstanding value for money. Benefits: Lubrication- and maintenance-free, quiet running, low friction, non-magnetic, washable, lightweight, good axial stability, long life cycle. |
- Brand / Quality:
- Igus - High Quality
- Inside Diameter:
- 20mm
- Outside Diameter:
- 44.5mm
- Width:
- 50mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d1 | 20mm |
|---|---|
| d2 | 44.5mm |
| d3 | 50mm |
| b1 | 37mm |
| b2 | 39 |
| Static load capacity | 210 N |
| Dynamic load capacity | 294 N |
| Limiting speed | 1150 rpm |
| Race | B180 |
| Cage | PA |
| Ball material | Glass |
