• Major Branded BH910 Imperial Drawn Cup Open End Type Full Complement Needle Roller Bearing 9/16x13/16x5/8 inch Allow 7-10 Days
1 1

SKU: BH-910

Major Branded BH910 Imperial Drawn Cup Open End Type Full Complement Needle Roller Bearing 9/16x13/16x5/8 inch Allow 7-10 Days

Major Branded BH910 Imperial Drawn Cup Open End Type Full Complement Needle Roller Bearing 9/16x13/16x5/8 inch Allow 7-10 Days
$19.57 ex VAT
$19.57 ex VAT
Sale Sold out

In stock

Price Break
5+ $13.11
9+ $12.37
19+ $12.22
29+ $12.08
49+ $11.93
74+ $11.78
99+ $11.04
199+ $10.90
249+ $10.75
499+ $10.60
999+ $10.31

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

Full Complement Needle Roller Bearings: Of similar construction to the common HK and TA series needle roller bearings but having no cage and twice the number of rollers occupying the same space to permit greater load carrying capacity. Often referred to as crowded roller construction.
Benefits: Compact space saving design, High load capacity.
Brand / Quality:
Major Brand - High Quality
Inside Diameter:
14.29mm = 0.563 (9/16) inch
Outside Diameter:
20.64mm = 0.813 (13/16) inch
Width:
15.88mm = 0.625 (5/8) inch
Technical
Inside Diameter 14.29mm = 0.5625 inch
Outside Diameter 20.64mm = 0.8125 inch
Width 15.88mm = 0.625 inch
Dynamic load C 15.4 kN
Static load Co 22.7 kN
S max 14.288mm = 0.5625 inch
S min 14.275mm = 0.562 inch
H max 20.65mm = 0.813 inch
H min 20.625mm = 0.812 inch
