• SKF BMB6202032S2EA002A Sensor Bearing Unit 15x35x11mm Allow 7-10 Days
1 1

SKU: BMB-6202/032S2/EA002A-SKF

SKF BMB6202032S2EA002A Sensor Bearing Unit 15x35x11mm Allow 7-10 Days

SKF BMB6202032S2EA002A Sensor Bearing Unit 15x35x11mm Allow 7-10 Days
$283.48 ex VAT
$283.48 ex VAT
Sale Sold out

Equivalent to: BMB-6204/032S2/UA002A

In stock

Price Break
3+ $189.88
5+ $179.21
9+ $177.08
14+ $174.95
15+ $172.81
20+ $170.68
49+ $160.01
99+ $157.88
249+ $155.75
499+ $153.61
999+ $149.34

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Sensor Bearings: Are classed as mechantronic machine components covering the fields of both bearing and sensor engineering component. They provide the ideal versatile combination of bearing and sensor. The sensors are shielded from external influences, the sensor body and impulse rings are mechanically attached to each other providing an integral ready to mount unit.
Benefits: Combined sensor / bearing
Brand / Quality:
SKF - High Quality
Inside Diameter:
15mm
Outside Diameter:
35mm
Width:
11mm
Seals / Shields:
Rubber Sealed
Clearance:
* Standard
Technical
d 15mm
D 35mm
B 11mm
Dynamic load Cr 8.06 kN
Static load Cor 3.75 kN
Fatigue load limit Pu 0.16 rpm
Limiting speed 13000 rpm
No of pulses 32
Period accuracy ±3%
Phase shift 90° ±30°
Weight 0.06 kg
d1 21.5mm
d2 19.5mm
D1 30.4mm
D2 34.4mm
b 1.35mm
C 2.06mm
r1r2 min 0.6mm
da min 19mm
db min 19mm
db max 19.4mm
Da max 31mm
ra max 0.6mm
Radial internal clearance min 11mm
Radial internal clearance max 25mm
