SKU: CNBH-192-SB-IKO
IKO CNBH192SB Heavy Duty Hex Head Sealed Cylindrical Cam Follower 6 inch Outside Diameter
IKO CNBH192SB Heavy Duty Hex Head Sealed Cylindrical Cam Follower 6 inch Outside Diameter
Out of stock
Description
Description
|
Heavy Duty Sealed Cam Follower with Hex Head: The outer race of this cam follower is high carbon chrome bearing steel through-hardened and ground. The studs and inner races are low carbon alloy steel carburized and induction hardened. This bearing contains a polymer type, lithium based grease containing corrosion resistant additives. This lubricant is suited to most bearing applications within a temperature range of 0 deg F to 250 deg F. Benefits: Suitable for many cam or track roller applications with moderate loading and shock, sealed to help prevent contamination and retain lubrication, provides ease of installing with a hex wrench. |
- Brand / Quality:
- IKO - High Quality
- Outside Diameter:
- 152.4mm = 6 inch
- Width:
- 82.55mm = 3.25 (3-1/4) inch
- Pitch:
- UNF 3-12
Technical
Technical
| A | 6 inch |
|---|---|
| B | 3.25 inch |
| C | 3 inch |
| D | 6 inch |
| E | 3 inch |
| Thread class 2A F | 3-12 UN |
| G | 1 inch |
| H | 3/16 inch |
| J | 1/4 inch |
| Min boss diameter | 4-15/32 inch |
| Recommended bore | 3 inch |
| Recommended torque | 5000 lbf-in |
| Max static capacity | 160900 lbs |
| Basic dynamic rating | 60000 lbs |
