M20x35 Metric Steel Cone Point Grub Screw 35mm Length 2.5mm Pitch

Steel Cone Point Grub Screws: Grub screws are used to fix rotating parts to shafts. Cone point grub screws have a pointed tip, designed for a more permanent installation they have the highest holding capability due to the precise contact of the cone point. They are headless screws which are threaded through a hole on the rotating part and tightened until the hexagon grub screw is flush with the shaft. This ensures the strength of the fixing while leaving no external extrusion. Grub screws are a small but extremely important part of many drive mechanisms and other machinery which uses moving and rotating parts.
Note: These set screws are designed for pressure loads and are not suitable for tensile- or shear loads.

Brand / Quality:

EU Budget - Economy Quality

Thread Size:

M20x35

Material:

Steel

Style:

Cone

Pitch:

2.5mm
