• SNR ESF209 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 45mm Bore - Allow 2-3 Days
  • SNR
1 2

SKU: ESF209-SNR

SNR ESF209 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 45mm Bore - Allow 2-3 Days

SNR ESF209 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 45mm Bore - Allow 2-3 Days
$58.91 ex VAT
$58.91 ex VAT
Sale Sold out

In stock

Price Break
3+ $39.46
4+ $37.25
9+ $36.80
19+ $36.36
49+ $35.91
99+ $35.47
499+ $33.25
999+ $32.81
1999+ $32.37
2999+ $31.92
4999+ $31.04

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
SNR - High Quality
Inside Diameter:
45mm
Style:
ESF
Bolt Hole Centres:
105mm
Technical
--- Dimensions
Shaft diameter d 45mm
A 38mm
A1 16mm
A2 54.7mm
B 30.2mm
B1 43.7mm
d1 62mm
e 22mm
J 105mm
L 137mm
N 16mm
S 11mm
G M6x1
--- Load rating
Dynamic load C 31.85 kN
Static load C0 20.8 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 11.5 Nm
Mass 2.13 kg
