• SNR ESF210 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 50mm Bore - Allow 2-3 Days
  • SNR
1 2

SKU: ESF210-SNR

SNR ESF210 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 50mm Bore - Allow 2-3 Days

SNR ESF210 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 50mm Bore - Allow 2-3 Days
$66.59 ex VAT
$66.59 ex VAT
Sale Sold out

In stock

Price Break
3+ $44.61
4+ $42.10
9+ $41.60
19+ $41.10
49+ $40.60
99+ $40.10
499+ $37.59
999+ $37.09
1999+ $36.59
2999+ $36.09
4999+ $35.09

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
SNR - High Quality
Inside Diameter:
50mm
Style:
ESF
Bolt Hole Centres:
111mm
Technical
--- Dimensions
Shaft diameter d 50mm
A 40mm
A1 16mm
A2 54.7mm
B 30.2mm
B1 43.7mm
d1 67.2mm
e 22mm
J 111mm
L 143mm
N 16mm
S 11mm
G M6x1
--- Load rating
Dynamic load C 35.1 kN
Static load C0 23.2 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 11.5 Nm
Mass 2.5 kg
