• SNR EXF213 Metric Four Bolt Square Cast Iron Flange Housing with 65mm Bore Eccentric Collar Insert - Allow 2-3 Days
  • SNR
1 2

SKU: EXF213-SNR

SNR EXF213 Metric Four Bolt Square Cast Iron Flange Housing with 65mm Bore Eccentric Collar Insert - Allow 2-3 Days

SNR EXF213 Metric Four Bolt Square Cast Iron Flange Housing with 65mm Bore Eccentric Collar Insert - Allow 2-3 Days
$117.40 ex VAT
$117.40 ex VAT
Sale Sold out

In stock

Price Break
3+ $78.64
4+ $74.22
9+ $73.34
19+ $72.46
49+ $71.57
99+ $70.69
499+ $66.27
999+ $65.39
1999+ $64.50
2999+ $63.62
4999+ $61.85

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
SNR - High Quality
Inside Diameter:
65mm
Style:
EXF
Bolt Hole Centres:
149mm
Technical
--- Dimensions
Shaft diameter d 65mm
A 50mm
A1 22mm
A2 81.6mm
B 68.2mm
B1 85.7mm
d1 86mm
e 30mm
J 149mm
L 187mm
N 19mm
S 34.1mm
G M6x1
--- Load rating
Dynamic load C 57.2 kN
Static load C0 40 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 22 Nm
Mass 6.03 kg
