SKU: EXF317-SNR
SNR EXF317 Metric Four Bolt Square Cast Iron Flange Housing with 85mm Bore Eccentric Collar Insert - Allow 2-3 Days
SNR EXF317 Metric Four Bolt Square Cast Iron Flange Housing with 85mm Bore Eccentric Collar Insert - Allow 2-3 Days
Regular price
$589.27
ex VAT
Regular price
Sale price
$589.27
ex VAT
In stock
Price Break
3+
$439.00
4+
$421.26
9+
$412.39
19+
$399.09
49+
$390.22
99+
$368.05
499+
$310.40
999+
$0.00
1999+
$0.00
2999+
$0.00
4999+
$0.00
Quantity
Couldn't load pickup availability
Description
Description
|
UCF or SF Series 4 Bolt Square Cast Iron Housings: Bearing units supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 85mm
- Style:
- EXF
- Bolt Hole Centres:
- 204mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 85mm |
| A | 74mm |
| A1 | 27mm |
| A2 | 111.5mm |
| B | 84.1mm |
| B1 | 109.5mm |
| d1 | 127mm |
| e | 44mm |
| J | 204mm |
| L | 260mm |
| N | 31mm |
| S | 42mm |
| G | M10x1 |
| --- | Load rating |
| Dynamic load C | 132.6 kN |
| Static load C0 | 96.5 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 64 Nm |
| Mass | 16.68 kg |
