• SNR EXFC211 Metric Four Bolt Cast Iron Round Flanged Housing with 55mm Eccentric Collar Insert - Allow 2-3 Days
  • SNR
1 2

SKU: EXFC211-SNR

SNR EXFC211 Metric Four Bolt Cast Iron Round Flanged Housing with 55mm Eccentric Collar Insert - Allow 2-3 Days

SNR EXFC211 Metric Four Bolt Cast Iron Round Flanged Housing with 55mm Eccentric Collar Insert - Allow 2-3 Days
$91.57 ex VAT
$91.57 ex VAT
Sale Sold out

In stock

Price Break
3+ $61.34
4+ $57.89
9+ $57.20
19+ $56.52
49+ $55.83
99+ $55.14
499+ $51.69
999+ $51.00
1999+ $50.31
2999+ $49.62
4999+ $48.25

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
SNR - High Quality
Inside Diameter:
55mm
Style:
EXFC
Pitch Circle Diameter:
150mm
Technical
--- Dimensions
Shaft diameter d 55mm
A 42mm
A1 13mm
A2 56.6mm
A4 30mm
B 55.4mm
B1 71.3mm
d1 74.5mm
e 13mm
H3 125mm
J 150mm
L 185mm
N 19mm
S 27.7mm
G M6x1
--- Load rating
Dynamic load C 43.55 kN
Static load C0 29.2 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 22 Nm
Mass 4.1 kg
