SKU: EXFC213-SNR
SNR EXFC213 Metric Four Bolt Cast Iron Round Flanged Housing with 65mm Eccentric Collar Insert - Allow 2-3 Days
SNR EXFC213 Metric Four Bolt Cast Iron Round Flanged Housing with 65mm Eccentric Collar Insert - Allow 2-3 Days
Regular price
$176.77
ex VAT
Regular price
Sale price
$176.77
ex VAT
In stock
Price Break
3+
$131.69
4+
$126.37
9+
$123.71
19+
$119.72
49+
$117.06
99+
$110.41
499+
$93.11
999+
$0.00
1999+
$0.00
2999+
$0.00
4999+
$0.00
Quantity
Couldn't load pickup availability
Share this product
Description
Description
EXFC200 Series 4 Bolt Cast Iron Round Flanged Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the round cast iron housing and include a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar with a grub screw to facilitate securing the bearing to the shaft after installation. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar/grub screw fixing
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 65mm
- Style:
- EXFC
- Pitch Circle Diameter:
- 170mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 65mm |
| A | 49mm |
| A1 | 15mm |
| A2 | 67.6mm |
| A4 | 35mm |
| B | 68.2mm |
| B1 | 85.7mm |
| d1 | 86mm |
| e | 16mm |
| H3 | 145mm |
| J | 170mm |
| L | 205mm |
| N | 19mm |
| S | 34.1mm |
| G | M6x1 |
| --- | Load rating |
| Dynamic load C | 57.2 kN |
| Static load C0 | 40 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 22 Nm |
| Mass | 6.03 kg |
