• SNR EXFE204 Metric Four Bolt Square Cast Iron Flange Housing with 20mm Bore Eccentric Collar Insert - Allow 2-3 Days
  • SNR
1 2

SKU: EXFE204-SNR

SNR EXFE204 Metric Four Bolt Square Cast Iron Flange Housing with 20mm Bore Eccentric Collar Insert - Allow 2-3 Days

SNR EXFE204 Metric Four Bolt Square Cast Iron Flange Housing with 20mm Bore Eccentric Collar Insert - Allow 2-3 Days
$29.88 ex VAT
$29.88 ex VAT
Sale Sold out

In stock

Price Break
3+ $20.02
4+ $18.89
9+ $18.67
19+ $18.44
49+ $18.22
99+ $17.99
499+ $16.87
999+ $16.64
1999+ $16.42
2999+ $16.19
4999+ $15.74

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
SNR - High Quality
Inside Diameter:
20mm
Style:
EXFE
Bolt Hole Centres:
63.5mm
Technical
--- Dimensions
Shaft diameter 20mm
A 29.5mm
A1 10mm
A2 45.5mm
B 34mm
B1 43.5mm
d1 32.4mm
e 19mm
J 63.5mm
L 86mm
N 11.5mm
S 17mm
G R1/8″
--- Load rating
Dynamic load C 12.8 kN
Static load C0 6.65 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 5.5 Nm
Mass 0.72 kg
