SKU: EXFE213N-SNR

SNR EXFE213N Metric Four Bolt Square Cast Iron Flange Housing with 65mm Bore Eccentric Collar Insert - Allow 2-3 Days

SNR EXFE213N Metric Four Bolt Square Cast Iron Flange Housing with 65mm Bore Eccentric Collar Insert - Allow 2-3 Days
Regular price $206.18 ex VAT
Regular price Sale price $206.18 ex VAT
Sale Sold out

In stock

Price Break
3+ $153.60
4+ $147.39
9+ $144.29
19+ $139.64
49+ $136.53
99+ $128.77
499+ $108.61
999+ $0.00
1999+ $0.00
2999+ $0.00
4999+ $0.00
Quantity

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
--- Dimensions
Shaft diameter 65mm
A 56mm
A1 18mm
A2 89.6mm
B 68.2mm
B1 85.7mm
d1 86mm
e 38mm
J 150mm
L 188mm
N 18mm
S 34.1mm
G R1/8″
--- Load rating
Dynamic load C 57.2 kN
Static load C0 40 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 22 Nm
Mass 6.85 kg
