SKU: F50B-MB

Major Branded F50B-MB Drive Coupling Pilot Bore Max Bore 38mm

Major Branded F50B-MB Drive Coupling Pilot Bore Max Bore 38mm
$32.53 ex VAT
$32.53 ex VAT
Sale Sold out

Equivalent to: F50B

In stock

Price Break
10+ $21.79
19+ $20.56
29+ $20.32
39+ $20.07
49+ $19.83
74+ $19.58
99+ $18.36
199+ $18.12
249+ $17.87
499+ $17.63
999+ $17.14

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Major Brand - High Quality
Max Bore:
38mm
Technical
B Type - Max Bore 38mm
B Type - Flange A 133mm
B Type - Flange C 100mm
B Type - Flange E 12.5mm
B Type - Flange G 38mm
B Type - Flange D 79mm
B Type - Flange Weight 1.72kg
B Type - Inertia 0.00115kgm2
B Type - Flange Face Spacing 25mm
B Type - Gap Between Tyre Ends 2mm
B Type - Nominal Torque 66 Nm
B Type - Max Speed 4500 rev/min
B Type - Max Par Mis 1.3mm
B Type - Max End Float 1.7mm
B Type - Screw Size M6
B Type - Tigtening Torque 15 Nm
Max Power at 100 rpm 0.69 kW
Max Power at 200 rpm 1.38 kW
Max Power at 300 rpm 2.07 kW
Max Power at 400 rpm 2.76 kW
Max Power at 500 rpm 3.46 kW
Max Power at 600 rpm 4.15 kW
Max Power at 700 rpm 4.84 kW
Max Power at 720 rpm 4.98 kW
Max Power at 800 rpm 5.53 kW
Max Power at 900 rpm 6.22 kW
Max Power at 960 rpm 6.63 kW
Max Power at 1000 rpm 6.91 kW
Max Power at 1200 rpm 8.29 kW
Max Power at 1400 rpm 9.68 kW
Max Power at 1440 rpm 9.95 kW
Max Power at 1600 rpm 11.1 kW
Max Power at 1800 rpm 12.4 kW
Max Power at 2000 rpm 13.8 kW
Max Power at 2200 rpm 15.2 kW
Max Power at 2400 rpm 16.6 kW
Max Power at 2600 rpm 18 kW
Maximum Speed 4500 rev/min
Nominal Torque 66 Nm TKN
Maximum Torque 160 Nm TK MAX
Torsional Stiffness 13 Nm/°
Max. Parallel Misalignment 1.3mm
Maximum End Float 1.7mm ±
Approximate Mass 0.3kg
Alternating Torque 26 ± Nm @ 10Hz TKW
Resonance Factor V B 7
Damping Coefficient Ø 0.9
