SKU: FC30DEC-RHP

RHP FC30DEC-RHP Four Bolt Round Cast Iron Flanged Bearing Unit and 30mm Insert

RHP FC30DEC-RHP Four Bolt Round Cast Iron Flanged Bearing Unit and 30mm Insert
$82.43 ex VAT
$82.43 ex VAT
Sale Sold out

In stock

Price Break
10+ $55.21
20+ $52.11
30+ $51.49
40+ $50.87
50+ $50.25
75+ $49.63
100+ $46.53
200+ $45.91
250+ $45.29
500+ $44.67
1000+ $43.43

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
30mm
Style:
FC
Pitch Circle Diameter:
100mm
Technical
Bore 30mm
L 125mm
H 80mm
J 100mm
G 10mm
A 20.5mm
A3 28.1mm
A5 9.5mm
B3 48.42mm
s2 18.32mm
d2 44.45mm
Dynamic load 19500 N
Static load 11300 N
Rec max speed 5300 rpm
Weight 1.1 kg
Insert <a href="advanced_search_result.php?keywords=1030-30DECG+insonly">1030-30DECG Click Here</a>
Casting group 4
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
