SKU: FC35-RHP

RHP FC35-RHP Four Bolt Round Cast Iron Flanged Bearing Unit and 35mm Insert

RHP FC35-RHP Four Bolt Round Cast Iron Flanged Bearing Unit and 35mm Insert
$81.70 ex VAT
$81.70 ex VAT
Sale Sold out

In stock

Price Break
10+ $54.73
20+ $51.65
30+ $51.04
40+ $50.42
50+ $49.81
75+ $49.19
100+ $46.12
200+ $45.50
250+ $44.89
500+ $44.27
1000+ $43.04

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
35mm
Style:
FC
Pitch Circle Diameter:
110mm
Technical
Bore 35mm
L 135mm
H 90mm
J 110mm
G 10mm
A 20.5mm
A1 24.4mm
A5 10mm
B 42.88mm
s 17.53mm
d1 46.69mm
Dynamic load 25700 N
Static load 15300 N
Rec max speed 4500 rpm
Weight 1.5 kg
Insert <a href="advanced_search_result.php?keywords=1035-35G+insonly">1035-35G Click Here</a>
Casting group 5
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
