SKU: FC45W209PPB5
RHP FC45 Four Bolt Round Cast Iron Flanged Bearing Unit and W209PPB5 Insert
RHP FC45 Four Bolt Round Cast Iron Flanged Bearing Unit and W209PPB5 Insert
Regular price
$177.89
ex VAT
Regular price
Sale price
$177.89
ex VAT
In stock
Price Break
10+
$119.15
20+
$112.46
30+
$111.12
40+
$109.78
50+
$108.44
75+
$107.10
100+
$100.41
200+
$99.07
250+
$97.73
500+
$96.39
1000+
$93.71
Quantity
Couldn't load pickup availability
Share this product
Description
Description
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 45mm
- Style:
- FC
- Pitch Circle Diameter:
- 130mm
Technical
Technical
| Bore | 45mm |
|---|---|
| L | 155mm |
| H | 105mm |
| J | 130mm |
| G | 12mm |
| A | 25mm |
| A1 | 28.18mm |
| A5 | 12mm |
| B | 49.23mm |
| s | 19.1mm |
| d1 | 57.3mm |
| Dynamic load | 32500 N |
| Static load | 20500 N |
| Rec max speed | 3700 rpm |
| Weight | 2.2 kg |
| Insert | <a href="advanced_search_result.php?keywords=W209PPB5+insonly">W209PPB5 Click Here</a> |
| Casting group | 7 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
