• SKF FY3/4TF/VA228 Y Bearing Four Bolt Square High Temperature Flange Unit Housing with Graphite Cage Insert for Imperial Shaft 3/4inch
  • SKF FY3/4TF/VA228 Y Bearing Four Bolt Square High Temperature Flange Unit Housing with Graphite Cage Insert for Imperial Shaft 3/4inch
  • SKF FY3/4TF/VA228 Y Bearing Four Bolt Square High Temperature Flange Unit Housing with Graphite Cage Insert for Imperial Shaft 3/4inch
1 3

SKU: FY3/4TF/VA228-SKF

SKF FY3/4TF/VA228 Y Bearing Four Bolt Square High Temperature Flange Unit Housing with Graphite Cage Insert for Imperial Shaft 3/4inch

SKF FY3/4TF/VA228 Y Bearing Four Bolt Square High Temperature Flange Unit Housing with Graphite Cage Insert for Imperial Shaft 3/4inch
$202.13 ex VAT
$202.13 ex VAT
Sale Sold out

In stock

Price Break
10+ $135.40
19+ $127.79
29+ $126.27
39+ $124.75
49+ $123.23
74+ $121.70
99+ $114.10
199+ $112.58
249+ $111.06
499+ $109.53
999+ $106.49

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF High Temperature Housings and Bearing Inserts: VA228 have a grey cast iron housing and have a coronet type graphite cages, they are lubricated with a polyalkylene glycol/graphite mixture and can be used at temperatures from -50 deg to +350 deg Celsius, at prolonged use over 200 deg Celsius dry lubricant pertains. All versions are characterised by their BLACK PHOSPHATED COATING on the inserts. They have a max rotational speed of 100 rpm
Benefits:High temp tolerance from -50 to +350 deg Celsius
Brand / Quality:
SKF - High Quality
Inside Diameter:
19.05mm = 0.75 (3/4) inch
Temperature Range:
High Temp
Technical
d 3/4 inch
A1 29.5mm
A2 11mm
B 31mm
J 63.5mm
L 86mm
N 11.1mm
G 10mm
T 37.3mm
Dynamic load C 12.7 kN
Static load Co 6.55 kN
Weight 0.63 kg
