• SKF FY40TFVA228 Y Bearing Four Bolt Square High Temperature Flange Unit Housing with Graphite Cage Insert for Metric Shaft 40mm
1 1

SKU: FY40TF/VA228-SKF

SKF FY40TFVA228 Y Bearing Four Bolt Square High Temperature Flange Unit Housing with Graphite Cage Insert for Metric Shaft 40mm

SKF FY40TFVA228 Y Bearing Four Bolt Square High Temperature Flange Unit Housing with Graphite Cage Insert for Metric Shaft 40mm
$365.19 ex VAT
$365.19 ex VAT
Sale Sold out

In stock

Price Break
10+ $244.62
19+ $230.87
29+ $228.12
39+ $225.38
49+ $222.63
74+ $219.88
99+ $206.14
199+ $203.39
249+ $200.64
499+ $197.89
999+ $192.39

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF High Temperature Housings and Bearing Inserts: VA228 have a grey cast iron housing and have a coronet type graphite cages, they are lubricated with a polyalkylene glycol/graphite mixture and can be used at temperatures from -50 deg to +350 deg Celsius, at prolonged use over 200 deg Celsius dry lubricant pertains. All versions are characterised by their BLACK PHOSPHATED COATING on the inserts. They have a max rotational speed of 100 rpm
Benefits:High temp tolerance from -50 to +350 deg Celsius
Brand / Quality:
SKF - High Quality
Inside Diameter:
40mm
Temperature Range:
High Temp
Technical
d 40mm
A1 38.5mm
A2 14mm
B 49.2mm
J 101.5mm
L 130mm
N 14.3mm
G 12mm
T 54.2mm
Dynamic load C 30.7 kN
Static load Co 19 kN
Weight 1.9 kg
