• SKF FYT1-1/4RM Oval Cast Housing with Grub Screw 1-1/4 inch Insert
1 1

SKU: FYT1.1/4RM-SKF

SKF FYT1-1/4RM Oval Cast Housing with Grub Screw 1-1/4 inch Insert

SKF FYT1-1/4RM Oval Cast Housing with Grub Screw 1-1/4 inch Insert
$60.39 ex VAT
$60.39 ex VAT
Sale Sold out

In stock

Price Break
10+ $40.45
20+ $38.18
30+ $37.72
40+ $37.27
50+ $36.82
75+ $36.36
100+ $34.09
200+ $33.63
250+ $33.18
500+ $32.73
1000+ $31.82

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Oval Flanged Y-bearing Units with Cast Housing and Grub Screws: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads.
Benefits: Grease fitting allows re-lubrication
Brand / Quality:
SKF - High Quality
Inside Diameter:
31.75mm = 1.25 (1-1/4) inch
Style:
FYT
Bolt Hole Centres:
130.2mm
Technical
d 1-1/4 inch
A1 34.5mm
A2 13mm
B 35mm
H 156mm
J 130.2mm
L 96mm
N 14.3mm
G 12mm
s1 25.5mm
T 46.4mm
Static load Cr 15.3 kN
Dynamic load Cor 25.5 kN
Fatigue load limit 0.655 kN
Limiting speed 5300 rpm
Weight 1.21 kg
Housing Insert
