• GE200ES Spherical Plain Bearing 200x290x130x100mm
1 1

SKU: GE200ES.EU

GE200ES Spherical Plain Bearing 200x290x130x100mm

GE200ES Spherical Plain Bearing 200x290x130x100mm
$1,292.57 ex VAT
$1,292.57 ex VAT
Sale Sold out

In stock

Price Break
10+ $865.80
19+ $817.16
29+ $807.43
39+ $797.70
49+ $787.98
74+ $778.25
99+ $729.61
199+ $719.88
249+ $710.15
499+ $700.42
999+ $680.97

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Spherical Plain Bearing: Consisting of steel raceway / body with a Gcr15 hardened Chrome steel ball (58-64 HRC) provided with an oil hole and groove
Benefits: Cost effective replacement bearing, sliding surfaces are steel against steel
Note: The outer raceway may have as part of the manufacturing process a split or crack
Brand / Quality:
Simply Spherical Plain - Economy Quality
Inside Diameter:
200mm
Outside Diameter:
290mm
Width:
130mm
Technical
d 200mm
D 290mm
B 130mm
C 100mm
dk 250mm
rs min 1.1mm
r1s min 1.1mm
Angle α 7°
Dynamic load Co 2120 kN
Static load Cor 10600 kN
Weight 28.03 kg
