SKU: GR/PS30/17B-12MM

PS30/17B-12 Metric Glass Filled Nylon Spur Gear 17 Tooth 3 Mod Pilot Bored 12mm

Name: PS30/17B-12 Metric Glass Filled Nylon Spur Gear 17 Tooth 3 Mod Pilot Bored 12mm
Brand: Drive-Flex
SKU: GR/PS30/17B-12MM
Price: 44.59 USD
Availability: InStock

$44.59 ex VAT

Sale Sold out

In stock

Price Break

5+ $29.87

9+ $28.19

19+ $27.85

29+ $27.52

49+ $27.18

74+ $26.85

99+ $25.17

199+ $24.83

249+ $24.50

499+ $24.16

999+ $23.49

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: Drive-Flex - High Quality
Bore:: 12mm
Number of Teeth:: 17
Variant:: Tooth Profile B
Pitch Circle Diameter:: 51mm
Gear Modulus:: 3 Mod

Technical

Number of Teeth	17
Pitch (B)	51mm
Pre-Bore	12mm
Hub / Boss Diameter (D)	24mm
Outside Diameter (A)	57mm
O/A Width (F)	45mm
Face Width (G)	30mm
Modulus or Mod	3 Mod
Pressure Angle	20 degrees
Bore Tolerance	Typically 0.5 - 1mm Undersized
Standard Tolerance	+ - 0.25mm
