SKU: GR/SS10DP/15B-0.75_INCH

SS10DP/15B-0.75 Imperial EN8 Steel Spur Gear 15 Tooth 10 DP Bored 0.75 inch (H8)

Name: SS10DP/15B-0.75 Imperial EN8 Steel Spur Gear 15 Tooth 10 DP Bored 0.75 inch (H8)
Brand: Drive-Flex
SKU: GR/SS10DP/15B-0.75_INCH
Price: 96.57 USD
Availability: InStock

$96.57 ex VAT

Sale Sold out

In stock

Price Break

5+ $64.68

9+ $61.05

19+ $60.32

29+ $59.60

49+ $58.87

74+ $58.14

99+ $54.51

199+ $53.78

249+ $53.06

499+ $52.33

999+ $50.87

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: Drive-Flex - High Quality
Bore:: 19.05mm = 0.75 (3/4) inch
Number of Teeth:: 15
Variant:: Tooth Profile B
Pitch Circle Diameter:: 38.1mm = 1.5 (1-1/2) inch
Gear Modulus:: 10DP

Technical

Number of Teeth	15
Pitch (dp)	1.5 inch
Bore (H8)	0.75 inch
Hub / Boss (dm)	1.125 inch
Outside (de)	1.7 inch
Width (A)	1.625 inch
Face Width (B)	1 inch
Modulus / Diametral Pitch DP	10 dp
Tolerance unless otherwise stated	+- 0.01 inch
Pressure Angle	20 degrees

Reviews

View full details
