SKU: GR/SS10DP/16B-0.75_INCH

SS10DP/16B-0.75 Imperial EN8 Steel Spur Gear 16 Tooth 10 DP Bored 0.75 inch (H8)

Name: SS10DP/16B-0.75 Imperial EN8 Steel Spur Gear 16 Tooth 10 DP Bored 0.75 inch (H8)
Brand: Drive-Flex
SKU: GR/SS10DP/16B-0.75_INCH
Price: 94.63 USD
Availability: InStock

$94.63 ex VAT

Sale Sold out

In stock

Price Break

5+ $63.38

9+ $59.82

19+ $59.11

29+ $58.40

49+ $57.69

74+ $56.97

99+ $53.41

199+ $52.70

249+ $51.99

499+ $51.28

999+ $49.85

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: Drive-Flex - High Quality
Bore:: 19.05mm = 0.75 (3/4) inch
Number of Teeth:: 16
Variant:: Tooth Profile B
Pitch Circle Diameter:: 40.64mm = 1.6 inch
Gear Modulus:: 10DP

Technical

Number of Teeth	16
Pitch (dp)	1.6 inch
Bore (H8)	0.75 inch
Hub / Boss (dm)	1.25 inch
Outside (de)	1.8 inch
Width (A)	1.625 inch
Face Width (B)	1 inch
Modulus / Diametral Pitch DP	10 dp
Tolerance unless otherwise stated	+- 0.01 inch
Pressure Angle	20 degrees
