SKU: GR/SS10DP/18B-0.75_INCH

SS10DP/18B-0.75 Imperial EN8 Steel Spur Gear 18 Tooth 10 DP Bored 0.75 inch (H8)

Name: SS10DP/18B-0.75 Imperial EN8 Steel Spur Gear 18 Tooth 10 DP Bored 0.75 inch (H8)
Brand: Drive-Flex
SKU: GR/SS10DP/18B-0.75_INCH
Price: 97.67 USD
Availability: InStock

$97.67 ex VAT

Sale Sold out

In stock

Price Break

5+ $65.43

9+ $61.75

19+ $61.02

29+ $60.28

49+ $59.55

74+ $58.81

99+ $55.14

199+ $54.40

249+ $53.66

499+ $52.93

999+ $51.46

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: Drive-Flex - High Quality
Bore:: 19.05mm = 0.75 (3/4) inch
Number of Teeth:: 18
Variant:: Tooth Profile B
Pitch Circle Diameter:: 45.72mm = 1.8 inch
Gear Modulus:: 10DP

Technical

Number of Teeth	18
Pitch (dp)	1.8 inch
Bore (H8)	0.75 inch
Hub / Boss (dm)	1.375 inch
Outside (de)	2 inch
Width (A)	1.625 inch
Face Width (B)	1 inch
Modulus / Diametral Pitch DP	10 dp
Tolerance unless otherwise stated	+- 0.01 inch
Pressure Angle	20 degrees
