SKU: GR/SS10DP/30B-0.75_INCH

SS10DP/30B-0.75 Imperial EN8 Steel Spur Gear 30 Tooth 10 DP Bored 0.75 inch (H8)

Name: SS10DP/30B-0.75 Imperial EN8 Steel Spur Gear 30 Tooth 10 DP Bored 0.75 inch (H8)
Brand: Drive-Flex
SKU: GR/SS10DP/30B-0.75_INCH
Price: 129.03 USD
Availability: InStock

$129.03 ex VAT

Sale Sold out

In stock

Price Break

5+ $86.43

9+ $81.57

19+ $80.60

29+ $79.63

49+ $78.66

74+ $77.69

99+ $72.83

199+ $71.86

249+ $70.89

499+ $69.92

999+ $67.98

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: Drive-Flex - High Quality
Bore:: 19.05mm = 0.75 (3/4) inch
Number of Teeth:: 30
Variant:: Tooth Profile B
Pitch Circle Diameter:: 76.2mm = 3 inch
Gear Modulus:: 10DP

Technical

Number of Teeth	30
Pitch (dp)	3 inch
Bore (H8)	0.75 inch
Hub / Boss (dm)	1.5 inch
Outside (de)	3.2 inch
Width (A)	1.875 inch
Face Width (B)	1 inch
Modulus / Diametral Pitch DP	10 dp
Tolerance unless otherwise stated	+- 0.01 inch
Pressure Angle	20 degrees
