SKU: GR/SS12DP/60B-0.75_INCH

SS12DP/60B-0.75 Imperial EN8 Steel Spur Gear 60 Tooth 12 DP Bored 0.75 inch (H8)

Name: SS12DP/60B-0.75 Imperial EN8 Steel Spur Gear 60 Tooth 12 DP Bored 0.75 inch (H8)
Brand: Drive-Flex
SKU: GR/SS12DP/60B-0.75_INCH
Price: 160.09 USD
Availability: InStock

$160.09 ex VAT

Sale Sold out

In stock

Price Break

5+ $107.23

9+ $101.21

19+ $100.00

29+ $98.80

49+ $97.59

74+ $96.39

99+ $90.37

199+ $89.16

249+ $87.96

499+ $86.75

999+ $84.34

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: Drive-Flex - High Quality
Bore:: 19.05mm = 0.75 (3/4) inch
Number of Teeth:: 60
Variant:: Tooth Profile B
Pitch Circle Diameter:: 127mm = 5 inch
Gear Modulus:: 12DP

Technical

Number of Teeth	60
Pitch (dp)	5 inch
Bore (H8)	0.75 inch
Hub / Boss (dm)	2.5 inch
Outside (de)	5.167 inch
Width (A)	1.5 inch
Face Width (B)	0.75 inch
Modulus / Diametral Pitch DP	12 dp
Tolerance unless otherwise stated	+- 0.01 inch
Pressure Angle	20 degrees
