• SSB15/20B-8 Metric EN8 Spur Gear 20 Tooth 1.5 Mod Pilot Bored 10mm Or Smaller (H8) Black Oxide Finish
1 1

SKU: GR/SSB15/20B-8MM

SSB15/20B-8 Metric EN8 Spur Gear 20 Tooth 1.5 Mod Pilot Bored 10mm Or Smaller (H8) Black Oxide Finish

SSB15/20B-8 Metric EN8 Spur Gear 20 Tooth 1.5 Mod Pilot Bored 10mm Or Smaller (H8) Black Oxide Finish
$15.97 ex VAT
$15.97 ex VAT
Sale Sold out

In stock

Price Break
5+ $10.69
9+ $10.09
19+ $9.97
29+ $9.85
49+ $9.73
74+ $9.61
99+ $9.01
199+ $8.89
249+ $8.77
499+ $8.65
999+ $8.41

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Drive-Flex - High Quality
Bore:
10mm
Number of Teeth:
20
Variant:
Tooth Profile B
Pitch Circle Diameter:
30mm
Gear Modulus:
1.5 Mod
Technical
Number of teeth 20
Pitch Diameter (dp) 30mm
Bore (H8) 10mm Or Smaller
Hub / Boss Diameter (dm) 24mm
Outside Diameter (de) 33mm
Width (A) 25mm
Face Width (B) 15mm
Gear Modulus or Mod 1.5 Mod
Pressure Angle 20 degrees
