SKU: HFL.1826
HFL1826 Budget Needle Roller Clutch Type One Way Bearing 18x24x26mm
HFL1826 Budget Needle Roller Clutch Type One Way Bearing 18x24x26mm
Out of stock
Share this product
Description
Description
|
Budget Metric Needle Roller Clutch Bearings: Designed to transmit torques in one direction and freewheel in the opposite direction. One-way clutches consist of a thin-walled, drawn outer ring with a series of ramps on the inside diameter, plastic cages, springs and needle rollers. They are supplied pre-greased with lithium soap grease. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 18mm
- Outside Diameter:
- 24mm
- Width:
- 26mm
Technical
Technical
| Fw | 18mm |
|---|---|
| D | 24mm |
| C | 26mm (Tolerance: 0/-0.3) |
| r min | 0.3mm |
| Permissable torque | 24.1 Nm |
| Speed (rotating shaft) | 7500 rpm |
| Speed (rotating outer ring) | 7500 rpm |
| Maximum permissable radial load | 8000 N |
| Limiting load | 10200 N/min |
| Weight | 25 g |
