SKU: HFL.3530.EU
HFL3530 Budget Needle Roller Clutch Type One Way Bearing 35x42x30mm
In stock
Price Break
Couldn't load pickup availability
Share this product
Description
|
Budget Metric Needle Roller Clutch Bearings: Designed to transmit torques in one direction and freewheel in the opposite direction. One-way clutches consist of a thin-walled, drawn outer ring with a series of ramps on the inside diameter, plastic cages, springs and needle rollers. They are supplied pre-greased with lithium soap grease. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 35mm
- Outside Diameter:
- 42mm
- Width:
- 30mm
Technical
| Fw | 35mm |
|---|---|
| D | 42mm |
| C | 30mm (Tolerance: 0/-0.3) |
| r min | 0.3mm |
| Permissable torque | 121 Nm |
| Speed (rotating shaft) | 3900 rpm |
| Speed (rotating outer ring) | 3900 rpm |
| Maximum permissable radial load | 12200 N |
| Limiting load | 18800 N/min |
| Weight | 58 g |
