SKU: HGZ120-JCS
JCS HGZ120 Zinc Plated Steel Hi-Grip Hose Clip Adjustment Range 90-120mm Band Width 13mm
JCS HGZ120 Zinc Plated Steel Hi-Grip Hose Clip Adjustment Range 90-120mm Band Width 13mm
Regular price
$6.03
ex VAT
Regular price
Sale price
$6.03
ex VAT
In stock
Price Break
5+
$3.18
10+
$2.72
20+
$2.50
50+
$2.27
100+
$1.82
500+
$1.59
1000+
$1.36
Quantity
Couldn't load pickup availability
Share this product
Description
Description
Zinc Plated Steel Hi-Grip Worm Drive Hose Clips: Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse. They are manufactured to exceed BS5315, which has the highest requirements of any of the international standards and tests sealing ability, clamping force and torque.
- Brand / Quality:
- JCS - High Quality
- Width:
- 13mm
- Min Adjustment Range:
- 90mm
- Max Adjustment Range:
- 120mm
Technical
Technical
| BS No. | 120 |
|---|---|
| Adjustment Range (mm) | 90-120mm |
| Adjustment Range (inch) | 3-1/2 - 4-3/4 inch |
| A | 13mm |
| B | 20mm |
| C | 12mm |
| D | 16mm |
| E | 13mm |
| F | 0.9mm |
| Screw | 7mm A/F |
| Recommended Torque Nm | 6Nm |
| Recommended Torque lb-in | 54lb-in |
