P15-3M-15F - 3mm Pitch 15 Tooth Flanged HTD Type Aluminium Timing Pulley for 15mm Wide Belts

SKU: HP15-3M-15F

P15-3M-15F - 3mm Pitch 15 Tooth Flanged HTD Type Aluminium Timing Pulley for 15mm Wide Belts

$12.96 ex VAT
$12.96
ex VAT
Equivalent to: 153M15F
In stock

Quantity Price Breaks

3 $11.53
5 $10.89
9 $10.76
19 $10.63
49 $10.50
74 $10.37
99 $9.72
199 $9.59
249 $9.46
499 $9.33
999 $9.07
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
P15-3M-15F - 3mm Pitch 15 Tooth Flanged HTD Type Aluminium Timing Pulley for 15mm Wide Belts
SKU: HP15-3M-15F

P15-3M-15F - 3mm Pitch 15 Tooth Flanged HTD Type Aluminium Timing Pulley for 15mm Wide Belts

$12.96 ex VAT
$12.96
ex VAT

Description

HTD Un-Bored Pilot Bore Timing Pulley: These High Torque Drive (HTD) timing pulleys feature a pilot hole to ease in the creation of your own bore size; ideal for bespoke applications and unusual sized shafts. The pulleys depending on the size are made from either Aluminium 6082, C45 Steel with black oxide treated surface or Cast Iron EN-GJL-200 and black phosphate. Where applicable flanges are made from S235JR Steel. Timing belt life can be increased with the proper pulley reducing running costs of your machinery.
Benefits: Available in a wide range of diameters and a number of teeth along with standard widths.

Technical

--- = Pulley Dimensions
Pitch = 3mm
Number of Teeth = 15
Type = 0F Unbored
Dp = 14.32mm
De = 13.56mm
Df = 17.5mm
Dm = 17.5mm
F = 17mm
L = 26mm
= Weight
0.01kg = N/A
