SKU: K3x5x9TN-MB
Major Brand K3x5x9TN Needle Roller Cage Assembly 3x5x9mm
Major Brand K3x5x9TN Needle Roller Cage Assembly 3x5x9mm
Regular price
$6.02
ex VAT
Regular price
Sale price
$6.02
ex VAT
In stock
Price Break
10+
$4.03
19+
$3.80
29+
$3.76
39+
$3.71
49+
$3.67
74+
$3.62
99+
$3.40
199+
$3.35
249+
$3.31
499+
$3.26
999+
$3.17
Quantity
Couldn't load pickup availability
Description
Description
|
Needle Roller Cage Assemblies: A ready to mount, self contained bearing component, they enable bearing arrangements with a high load carrying capacity and stiffness yet only requiring a minimal amount of radial space if the shaft and housing serve as raceways. Generally made with steel cages with no specific maximum temperature or when suffixed with TN a glass fibre reinforced polyamide cage material having a maximum operating temperature 120 deg C Benefits: Low cost bearing solution, minimal radial space requirements, high running accuracy. |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 3mm
- Outside Diameter:
- 5mm
- Width:
- 9mm
Technical
Technical
| Fw | 3mm |
|---|---|
| Ew | 5mm |
| U | 9mm |
| Dynamic load | 1720 N |
| Static load | 1630 N |
| Fatigue load limit Pu | 170 N |
| Speed in grease | 28000 rpm |
| Speed in oil | 40000 rpm |
| Weight | 0.4 g |
