• INA KB12 Closed Linear Ball Bushing with Gap Seals 12x22x32mm
  • INA KB12 Closed Linear Ball Bushing with Gap Seals 12x22x32mm
  • INA KB12 Closed Linear Ball Bushing with Gap Seals 12x22x32mm
  • INA
1 4

SKU: KB12-INA

INA KB12 Closed Linear Ball Bushing with Gap Seals 12x22x32mm

INA KB12 Closed Linear Ball Bushing with Gap Seals 12x22x32mm
$54.54 ex VAT
$54.54 ex VAT
Sale Sold out

In stock

Price Break
3+ $36.53
5+ $34.48
10+ $34.07
15+ $33.66
20+ $33.25
30+ $32.84
40+ $30.79
50+ $30.38
60+ $29.97
75+ $29.56
100+ $28.74

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
INA KB Linear Ball Bearings: Linear ball bearings of the machined range KB and the corresponding linear ball bearing and housing units have high precision and are particularly rigid. These bearings are of a closed construction and are designed for use on shafts. The bearings are sealed on both sides with gap seals. They have an initial greasing and can be relubricated via a lubrication nipple in the housing. Bearings and housings of this product range can be used at operating temperatures from -30 deg C to +80 deg C.
Benefits: Closed construction makes this bearing suitable for use on shafts, excellent running characteristics, can be relubricated
Brand / Quality:
INA - High Quality
Inside Diameter:
12mm
Outside Diameter:
22mm
Width:
32mm
Technical
Fw 12mm
D 22mm
L 32mm
Numer of rows of balls 5
BL2 1.3mm
DN 21mm
L2 22.6mm
Mass 0.04 kg
Basic dynamic load rating C min 540 N
Basic static load rating C0 min 385 N
Basic dynamic load rating C max 640 N
Basic static load rating C0 max 570 N
Reviews
View full details
