SKU: KMFE6-SKF

SKF KMFE6 Lock Nut with Locking Screw M30x1.5mm

SKF KMFE6 Lock Nut with Locking Screw M30x1.5mm
$43.47 ex VAT
$43.47 ex VAT
Sale Sold out

In stock

Price Break
10+ $29.12
19+ $27.48
29+ $27.16
39+ $26.83
49+ $26.50
74+ $26.18
99+ $24.54
199+ $24.21
249+ $23.88
499+ $23.56
999+ $22.90

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

KMFE Lock Nuts: Featuring integrated locking screws are designed to securely position CARB toroidal roller bearings, sealed spherical roller bearings, and sealed self-aligning ball bearings on a shaft. They eliminate the need for a keyway, reducing shaft costs. Installation is fast and easy with the built-in set screw, and no separate locking device is needed. The maximum axial run-out for the locating face and thread is 0.02 to 0.03 mm.
Benefits: Efficient, secure, inexpensive, removable and re-usable

Brand / Quality:
SKF - High Quality
Thread Size:
M30x1.5
Technical
d1 36mm
d3 45mm
B 10.5mm
B1 8.5mm
b 5mm
h 2mm
Axial load capacity 36.5 kN
Looseing torque 42 Nm
Weight 0.058 kg
G M30x1.5
Designation KMFE6
Spanner HN6
Grub M5
Screw tightening torque 4 Nm
