SKU: KMK2-SKF

SKF KMK2 Lock Nut with Integral Locking Device M15x1mm

SKF KMK2 Lock Nut with Integral Locking Device M15x1mm
$40.76 ex VAT
$40.76 ex VAT
Sale Sold out

In stock

Price Break
10+ $27.31
19+ $25.77
29+ $25.47
39+ $25.16
49+ $24.85
74+ $24.55
99+ $23.01
199+ $22.71
249+ $22.40
499+ $22.09
999+ $21.48

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Precision KMK Lock Nuts: These lock nuts have an integral locking device consisting of a grub screw against a pressure plate that has the thread profile machined on it, When tightened there is no possibility of damaging the threads and mounting and dismounting are a simple operation. The outer perimeter of the nut has the usual slots for use of a nut spanner or socket. No additional lock washers or clips are required.
Benefits: Efficient, secure, inexpensive, removable and re-useable
Brand / Quality:
SKF - High Quality
Thread Size:
M15x1
Technical
d1 21mm
d3 25mm
B 9mm
b 4mm
h 2mm
Axial load capacity 14.6 kN
Loosening torque 12 Nm
Weight 0.021 kg
G M15x1
Designation KMK2
Locking device HN2
Grub screw M5
Grub screw torque 4 Nm
