• SKF KMK3 Lock Nut with Integral Locking Device M17x1mm
  • SKF KMK3 Lock Nut with Integral Locking Device M17x1mm
  • SKF KMK3 Lock Nut with Integral Locking Device M17x1mm
1 3

SKU: KMK3-SKF

SKF KMK3 Lock Nut with Integral Locking Device M17x1mm

SKF KMK3 Lock Nut with Integral Locking Device M17x1mm
$53.13 ex VAT
$53.13 ex VAT
Sale Sold out

In stock

Price Break
10+ $35.59
19+ $33.59
29+ $33.19
39+ $32.79
49+ $32.39
74+ $31.99
99+ $29.99
199+ $29.59
249+ $29.19
499+ $28.79
999+ $27.99

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Precision KMK Lock Nuts: These lock nuts have an integral locking device consisting of a grub screw against a pressure plate that has the thread profile machined on it, When tightened there is no possibility of damaging the threads and mounting and dismounting are a simple operation. The outer perimeter of the nut has the usual slots for use of a nut spanner or socket. No additional lock washers or clips are required.
Benefits: Efficient, secure, inexpensive, removable and re-useable
Brand / Quality:
SKF - High Quality
Thread Size:
M17x1
Technical
d1 24mm
d3 28mm
B 9mm
b 4mm
h 2mm
Axial load capacity 19.6 kN
Loosening torque 13 Nm
Weight 0.027 kg
G M17x1
Designation KMK3
Locking device HN3
Grub screw M5
Grub screw torque 4 Nm
