• SKF KMK9 Lock Nut with Integral Locking Device M45x1.5mm
  • SKF KMK9 Lock Nut with Integral Locking Device M45x1.5mm
  • SKF KMK9 Lock Nut with Integral Locking Device M45x1.5mm
1 3

SKU: KMK9-SKF

SKF KMK9 Lock Nut with Integral Locking Device M45x1.5mm

SKF KMK9 Lock Nut with Integral Locking Device M45x1.5mm
$65.70 ex VAT
$65.70 ex VAT
Sale Sold out

In stock

Price Break
10+ $44.01
19+ $41.54
29+ $41.05
39+ $40.55
49+ $40.06
74+ $39.56
99+ $37.09
199+ $36.60
249+ $36.10
499+ $35.61
999+ $34.62

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Precision KMK Lock Nuts: These lock nuts have an integral locking device consisting of a grub screw against a pressure plate that has the thread profile machined on it, When tightened there is no possibility of damaging the threads and mounting and dismounting are a simple operation. The outer perimeter of the nut has the usual slots for use of a nut spanner or socket. No additional lock washers or clips are required.
Benefits: Efficient, secure, inexpensive, removable and re-useable
Brand / Quality:
SKF - High Quality
Thread Size:
M45x1.5
Technical
d1 60mm
d3 65mm
B 11mm
b 6mm
h 2.5mm
Axial load capacity 78 kN
Loosening torque 76 Nm
Weight 0.14 kg
G M45x1.5
Designation KMK9
Locking device HN9
Grub screw M6
Grub screw torque 8 Nm
