SKU: KMT0-SKF

SKF KMT0 Precision Lock Nut with Locking Pins M10x0.75mm

SKF KMT0 Precision Lock Nut with Locking Pins M10x0.75mm
$107.39 ex VAT
$107.39 ex VAT
Sale Sold out

In stock

Price Break
10+ $71.93
19+ $67.89
29+ $67.08
39+ $66.27
49+ $65.46
74+ $64.65
99+ $60.61
199+ $59.81
249+ $59.00
499+ $58.19
999+ $56.57

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Precision KMT Lock Nuts: Manufactured with standard ISO threads and a relieved external diameter primarily used for precision bearing installation and a chamfered front face for ease of access to the radial locking pins mounted at 120 degrees around the perimeter and diagonally to the threads and allow for minor radial alignment adjustments.
Benefits: Efficient, secure, inexpensive, removable and re-useable
Brand / Quality:
SKF - High Quality
Thread Size:
M10x0.75
Technical
d1 21mm
d2 28mm
d3 23mm
d4 11mm
B 14mm
b 4mm
h 2mm
M 24mm
Axial load capacity 35 kN
Loosening torque 15 Nm
Weight 0.045 kg
G M10x0.75
Spanner HN2/3
Grub screw M5
Screw torque 4.5 Nm
