• SKF KMT13 Precision Lock Nut with Locking Pins M65x2mm
  • SKF KMT13 Precision Lock Nut with Locking Pins M65x2mm
  • SKF KMT13 Precision Lock Nut with Locking Pins M65x2mm
1 3

SKU: KMT13-SKF

SKF KMT13 Precision Lock Nut with Locking Pins M65x2mm

SKF KMT13 Precision Lock Nut with Locking Pins M65x2mm
$183.00 ex VAT
$183.00 ex VAT
Sale Sold out

In stock

Price Break
10+ $122.58
19+ $115.69
29+ $114.32
39+ $112.94
49+ $111.56
74+ $110.18
99+ $103.30
199+ $101.92
249+ $100.54
499+ $99.17
999+ $96.41

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Precision KMT Lock Nuts: Manufactured with standard ISO threads and a relieved external diameter primarily used for precision bearing installation and a chamfered front face for ease of access to the radial locking pins mounted at 120 degrees around the perimeter and diagonally to the threads and allow for minor radial alignment adjustments.
Benefits: Efficient, secure, inexpensive, removable and re-useable
Brand / Quality:
SKF - High Quality
Thread Size:
M65x2
Technical
d1 83mm
d2 95mm
d3 87mm
d4 68mm
B 28mm
b 8mm
h 3.5mm
M 90mm
Axial load capacity 460 kN
Loosening torque 265 Nm
Weight 0.71 kg
G M65x2
Spanner HN14
Grub screw M8
Screw torque 18 Nm
