• SKF KMT16 Precision Lock Nut with Locking Pins M80x2mm
1 1

SKU: KMT16-SKF

SKF KMT16 Precision Lock Nut with Locking Pins M80x2mm

SKF KMT16 Precision Lock Nut with Locking Pins M80x2mm
$201.06 ex VAT
$201.06 ex VAT
Sale Sold out

In stock

Price Break
10+ $134.68
19+ $127.11
29+ $125.60
39+ $124.08
49+ $122.57
74+ $121.06
99+ $113.49
199+ $111.98
249+ $110.46
499+ $108.95
999+ $105.93

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Precision KMT Lock Nuts: Manufactured with standard ISO threads and a relieved external diameter primarily used for precision bearing installation and a chamfered front face for ease of access to the radial locking pins mounted at 120 degrees around the perimeter and diagonally to the threads and allow for minor radial alignment adjustments.
Benefits: Efficient, secure, inexpensive, removable and re-useable
Brand / Quality:
SKF - High Quality
Thread Size:
M80x2
Technical
d1 98mm
d2 110mm
d3 100mm
d4 83mm
B 32mm
b 8mm
h 3.5mm
Axial load capacity 620 kN
Loosening torque 325 Nm
Weight 0.9 kg
G M80x2
Spanner HN16/17
Grub screw M8
Screw torque 18 Nm
